Question 1

What is a case packer machine?

Accepted Answer

A case packer machine is a secondary packaging system that picks finished primary packs , pouches, bottles, shrink packs, or bars , and loads them into outer shipping cases or cartons in the required matrix formation. It sits between the primary packaging stage and the end-of-line palletizing stage, and its job is to perform that transition at the speed and accuracy the line needs, with the case integrity that retail distribution partners require.

Question 2

What types of case packer machines does Cybernetik manufacture?

Accepted Answer

Cybernetik builds eight case packer machine variants: Case Packer for Pouches (single and multiple robots), Staggered Pouch Case Packer (two robots), Multiple SKU Case Packer, Horizontal Pouch Case Packer (SCARA), Case Packer for Bottles, Case Packer for Shrink Packs, Case Packer for Shrink Packs and Bottles (combo), and Chocolate Bar Case Packer. All are built on a common engineering platform and designed for integration with upstream primary packaging and downstream palletizing systems.

Question 3

What speed can a Cybernetik case packer machine reach?

Accepted Answer

Speed depends on the configuration and product. The Six-Axis Case Packer for Pouches reaches up to 40 pouches per minute with a 200 kg payload. The SCARA variant runs up to 12 pouches per minute with a 5 kg payload. The Case Packer for Bottles reaches up to 120 bottles per minute on the Six-Axis configuration. All speeds are customizable based on product and line requirements.

Question 4

Are Cybernetik case packer machines CE certified?

Accepted Answer

Yes. CE certification is standard across the Cybernetik case packer portfolio. All food and beverage configurations are built with GMP-compliant food-contact surfaces , stainless steel contact parts and food-grade gripper materials. For pharmaceutical applications, the line is built to the additional hygiene and traceability requirements of that regulatory environment.

Question 5

How does a case packer machine improve packing density for pouches?

Accepted Answer

Cybernetik’s Staggered Pouch Case Packer uses a vibratory conveyor to uniformize pouch thickness before the packing stage, and a staggered pouch lifting system that raises two pouches to slightly different heights before the robots load them. The deliberate overlap created by the stagger maximizes the number of pouches that fit into each case volume, reducing carton cost per unit shipped and improving pallet stability.
